2 Position Screw Terminal Block Low Profile
2 Position Screw Terminal Block Low Profile - Blue is backordered and will ship as soon as it is back in stock.
Ships Same Day if Ordered Before Noon Pacific Time
Introducing a lower profile version of our popular 2 position terminal blocks. Great for tight spaces!
These screw terminal blocks are compatible with all of our breadboards.
A nice feature is the slide-locking grooves which allow you to gang these together to create larger terminal blocks including ganging these together with our 3 position low profile terminal blocks to make terminal blocks the number of positions you need.
- 1 — 2 Position Screw Terminal Block Low Profile
|Max Voltage||300 V|
|Max Current||16 A|
|Compatible Wire Gauge||14 - 26 AWG|
|Spacing||5.08 mm (0.2")|
|Length||10.54 mm (0.415")|
|Width||7.8 mm (0.3")|
|Height||10.1 mm (0.39")|
|Pin Length||3.85 mm (0.152")|
|Pin Diameter||0.6 mm (0.023")|
